| Product No. | AE3510 | ||
| Working power supply | Single-phase three-wire AC 220V, frequency range: 40-60Hz | ||
| Mainframe operation mode | Touch screen | ||
| Display | 7“ TFT LCD screen, resolution 800* 480 | ||
| Data communication | CAN RS485 | ||
| Data dumping | USB | ||
| Data report | After the data is uploaded to the pc, the corresponding software can generate data reports | ||
| Internal data saving | 16G | ||
| Data search | Support in-memory data preview | ||
| Battery box data acquisition communication | CAN data bus | ||
| Module data acquisition communication | Wire harness sampling | ||
| Winding head voltage accuracy | ≤±0.5%FS+0.3V, minimum scale: 0.1V | ||
| Single voltage accuracy | ≤±0.1%FS+5mV, minimum scale: 0.001V | ||
| Accuracy of test current | ≤±1%FS+0.2A, minimum scale: 0.1A | ||
| Charging voltage range | DC 2-285V | ||
| Discharge voltage range | DC 2-285V | ||
| Charge current range | Maximum current: 100A, maximum power: 4.4kW | ||
| Discharge current range | Maximum current: 150A, maximum power: 7.2kw | ||
| Charge control | Constant current charging + constant voltage charging | ||
| Discharge mode | Constant-current discharge | ||
| Charge and discharge data collection | Internal active measurement + external CAN communication data acquisition | ||
| Charge and discharge protection of electric box | Protection of battery string over-charging, over-discharging, or overheating | ||
| Mainframe protection | Over temperature, over current or current out of control will trigger shutdown protection | ||
| Shutdown actuator | DC air break | ||
| Reverse polarity protection | Support | ||
| Fault protection | Power cable or main cable is powered off | ||
| Over-temperature protection | Resistance box over-temperature 85℃; Heat sink over-temperature 100℃ | ||
| Alarm | LCD + buzzer | ||
| Product size | 524x305x393mm | ||
| Product weight | 23.5kg | ||
| Warranty clause (Lifetime warranty/Partial warranty/Term Warranty/Non-warranty) | 1-year warranty | ||
