Product No. AE1027H-3
Gross/Net weight 432KG/ 380KG
Operating noise ≦70db
Maximum tire width 350MM
Large disk rotation speed 6-12rpm
Push-pull force of large cylinders 2500kgf
Operating air pressure 8-10Bar
Maximum tire diameter 1100MM
Warranty Terms 1 year (except consumable parts)
Rim diameter 13-28"
Package dimensions 1380x1130x1840MM
◆The pry-free module solves the troubles of flat tires and run-proof tires disassembly and scraping, and the operation is easier
◆The upper seat of the box column and the base are stiffened, the front end is closed, and the tire column is not easy to deform
◆Operate the mirror to improve work efficiency
◆Safety guardrails to protect the safety of people and tires
◆Aluminum alloy atmospheric cylinder, strong corrosion resistance
◆

The three-speed tire pressure shovel adjusts the opening and closing degree, which is more applicable

◆The high-pressure oil-water separator comes with a metal protective sleeve and is not easily damaged
