Product No. AE1018H-3
Internal support hub diameter 13"-26"
Gross/Net weight 375/300KG
Tire width 3"-14"
Diameter of the outer clamping rim 11"-24"
Oil-water separator pressure resistance 12KGf/CM²
Operating air pressure 8-10bar
Large disk rotation speed 6.5/13rpm
Push-pull force of large cylinders 2800KGf
Operating noise <70db
Maximum tire diameter 1100MM
Warranty Terms 1 year (except consumable parts)
Package dimensions 1280x1020x2000MM
Dual-speed motor, faster dismounting
No prying module, solve the flat tire and explosion-proof tire dismounting and scraping troubles, easier operation
Box column upper seat and base reinforcement, front closed, dismounting tire column is not easy to be deformed
New plastic front cover and base shroud
New hand-operated control valve, hexagonal axle running smoothly, comfortable to manipulate
Aluminum cylinder, shoveling the tire is more powerful, suitable for all kinds of hard-wall tires, anti-blowout tires
