| Product No. | 1 51034 | ||
| Battery No. | 151513 | ||
| Charger No. | 151502 | ||
| Battery | 4.0x2 | ||
| Voltage | 20 | ||
| Output（KN） | 105 | ||
| Ram stroke（mm） | 42 | ||
| Crimping cycles （Cu150mm²） | ≈120 | ||
| Crimping range（Cu）（mm²） | MAX.400mm² | ||
| Crimping range（Al）（mm²） | MAX.300mm² | ||
| Crimping times（s） | 10~13 | ||
| Charging time (MIN) | ≈80 | ||
| Crimping dies（mm²） | 10,16,25,35,50,70,95,120,150,185,240,300,400 | ||
| Unit weight (kg) | 7.58 | ||
| Warranty term | 24 Months | ||
| ◆ | Cell-balancing technology |
| ◆ | Intelligent chip control |
| ◆ | Digital LED display screen |
| ◆ | Continuous crimping technology |
| ◆ | Dual-Piston Hydraulic System |
| ◆ | Two-Stage Hydraulic System |
| ◆ | Temperature Sensor |
| ◆ | 330° Rotating Head |
