| Product No. | 1 51033 | ||
| Battery No. | 151513 | ||
| Charger No. | 151502 | ||
| Battery | 4.0x2 | ||
| Voltage | 20 | ||
| Output（KN） | 60 | ||
| Ram stroke（mm） | 32 | ||
| Crimping cycles （Cu150mm²） | ≈270 | ||
| Crimping range（Cu）（mm²） | MAX.300mm² | ||
| Crimping range（Al）（mm²） | MAX.240mm² | ||
| Crimping times（s） | 8~12 | ||
| Charging time (MIN) | ≈80 | ||
| Crimping dies（mm²） | 6,10,16,25,35,50,70,95,120,150,185,240,300 | ||
| Unit weight (kg) | 5.2 | ||
| Warranty term | 24 Months | ||
| ◆ | Cell-balancing technology |
| ◆ | Intelligent chip control |
| ◆ | Digital LED display screen |
| ◆ | Continuous crimping technology |
| ◆ | Dual-Piston Hydraulic System |
| ◆ | Two-Stage Hydraulic System |
| ◆ | Temperature Sensor |
| ◆ | 330° Rotating Head |
