| Product No. | 1 04054 | ||
| Interface size | G1" | ||
| Air Handling Capacity (M³/min) | 2.4 | ||
| Auto drain outlet size | G1/2" | ||
| Filtration precision | 3μm solid particles, 5ppm oil content | ||
| Working pressure (MPa) | ≤0.8 | ||
| Inlet temperature (°C) | ≤65 | ||
| Principle of Separation | Multi-layer filtration | ||
| Product dimensions (MM) | ⌀105x440 | ||
| Warranty Terms | One-year warranty (filter element excluded) | ||
| ◆ | Equipped with a float ball automatic drain valve for more convenient drainage |
| ◆ | Adopting multi-layer glass fiber filter element, with strong oil and dust removal capability |
| ◆ | 3.Resistant to high temperature of 65℃, with excellent service durability |
