| Product No. | 1 04052 | ||
| Interface size | G3/4" | ||
| Air Handling Capacity (M³/min) | 1.5 | ||
| Auto drain outlet size | G1/2" | ||
| Filtration precision | 0.01μm solid particles, 0.01ppm oil content | ||
| Working pressure (MPa) | ≤0.8 | ||
| Inlet temperature (°C) | ≤65 | ||
| Principle of Separation | Multi-layer filtration | ||
| Product dimensions (MM) | ⌀85x240 | ||
| Warranty Terms | One-year warranty (filter element excluded) | ||
| ◆ | Equipped with a float ball automatic drain valve for more convenient drainage |
| ◆ | Adopting multi-layer glass fiber filter element, with strong oil and dust removal capability |
| ◆ | Resistant to high temperature of 65℃, with excellent service durability |
